Age: 55

Sex: Male

Indication: Elbow pain

Save ("V")

Case #3


Findings

  • Age-indeterminate nondisplaced fracture of the sublime tubercle of the ulna
  • Mild ulnohumeral joint degenerative changes
  • Mild olecranon enthesopathy


Diagnosis

  • Sublime tubercle fracture

Sample Report

Age-indeterminate nondisplaced fracture of the sublime tubercle of the ulna.

No joint malalignment.

No elbow joint effusion.

Mild ulnohumeral joint degenerative changes.

Mild olecranon enthesopathy.


Discussion

  • The anterior bundle of the medial (ulnar) collateral ligament inserts on the sublime tubercle along the medial aspect of the coronoid process and is an important elbow stabilizer
  • Avulsion fractures of the sublime tubercle are not uncommon and can be very subtle
  • Just like Segond fractures in the knee, the sublime tubercle should be a specific part of your search pattern to avoid missing these fractures


Images

Red arrow: nondisplaced sublime tubercle fracture.
